Organizations & Universities Comprehensive Automation Systems
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
General features of UAS web based university automation comprehensive
دستگاه سری ایگل Eagle
Camera:
Kimia Series
As new generation of eagle series, Kimai series are available in smaller size and modern design
Almost the same as eagle series except for finger print sensor, built in camera and keypad.
Photo sensor:
the sensor surface is covered with light sensitive diodes. Diodes sense reflected light from finger’s surface and converted it to electric current, which goes to a processor to be converted into different grey spectrum to form a whole print of finger.
Main advantages:
The sensor is completely scratch resistant and rigid.
Technical features of photo sensor:
taking into account advantages and disadvantages of photo sensors available in the market, Jahan Gostar Company has selected Suprema sensor for its call roll systems. This sensor (made in Korea) brings us following features:
At each scan, the sensor produces two images, and through time choose the one with higher quality and delete the less quality image. Consequently the system modifies itself with changes in user’s fingers specifications.
دستگاه سری ایگل Eagle

Eagle series
Design features:
|
- Recording up to 362000 pictures in roll call field
- Exporting files through mmc, network, and RS2323
- Traffic control with no need for finger print identification system
- RS485, RS232 and printer output
- Two input and three output ports to be used for connecting gate and traffic controller modules
- Time announcement (coming and going)
- Setting different alarms for specific time of day
- Professional 16 bit processor
- GPRS for wireless communication with server
- Up to 16Mb memory (extendible)
- Designed for variety of weather conditions
- High voltage shock and noise protected
- Two working modes; offline & online
- Recording up to 262 records (extendible up to 2 million records)
- RS232, RS425 and printer port
- Two input and three output ports for connecting auxiliaries such as gate and kiosk
- Built in UPS (7hrs. charge, 4hrs. continuous work)
- Compatible with contactless and standard smartcard
- Hard disk for saving traffic, dates, and other data even when power is gone out
- Displaying personal information of card holder at holding the card before scanner
- Log display including date and time of power cut and disconnections
- Data delete prohibition even after exporting data
- Program setting through system menu and computer
- Offline convection through external modem
Kimia Series
As new generation of eagle series, Kimai series are available in smaller size and modern design
- Dimension: 3 * 9 * 14.5cm
- Weight: 200gr.
- Wide display screen with background light and keypad
Almost the same as eagle series except for finger print sensor, built in camera and keypad.
Photo sensor:
the sensor surface is covered with light sensitive diodes. Diodes sense reflected light from finger’s surface and converted it to electric current, which goes to a processor to be converted into different grey spectrum to form a whole print of finger.
Main advantages:
The sensor is completely scratch resistant and rigid.
Technical features of photo sensor:
taking into account advantages and disadvantages of photo sensors available in the market, Jahan Gostar Company has selected Suprema sensor for its call roll systems. This sensor (made in Korea) brings us following features:
- Resolution: 500dpi
- Number of scan for one record: 1
- Scan speed: 800ms
- Comparison: 800ms
- Search speed: 970ms between 1000 records
- Accuracy: 0.01% (failing to match a finger print)
- Working temperature: 0-60C⁰
- Working humidity: 10-80%
At each scan, the sensor produces two images, and through time choose the one with higher quality and delete the less quality image. Consequently the system modifies itself with changes in user’s fingers specifications.
